Jack Fuse FASTR4S 4-Way Quick Connect Splitter – Jack Fuse’s FASTR4S Quick Connect 4-Way Splitter is designed for efficient and reliable termination of RS485, OSDP, and 4-core card reader cables.
Developed for security and access control applications, the FASTR4S simplifies installation by eliminating soldering, crimping, and screw terminal connections. Instead, the system uses spring clamp terminals and a strip?twist?insert method that reduces installation time and limits potential faults.
Each connector accepts solid or stranded conductors and is colour coded to ensure correct wiring. The compact size of the splitter allows it to be installed in tight spaces such as wall cavities, ducting, or door frames. The system supports secure daisy chaining and termination of RS485 comms lines and is compatible with Wiegand and RS485-based keypads, access control readers, and powered locks.
The FASTR4S Quick Connect 4-Way Splitter is supplied in packs of 10 and supports up to 2 A current draw per channel. It is suitable for pre-fitting to security peripherals off-site to save on installation hours and streamline deployment.
You can learn more about Jack Fuse products here or read more SEN news here.
Jack Fuse FASTR4S 4-Way Quick Connect Splitter Features
4-way spring clamp quick connect terminals
Colour coded conductors
No solder, crimp, or screw terminals
Compact design – 22.5mm x 17.5mm x 13mm
2A max current draw
Supports RS485, OSDP, Wiegand, power and lock wiring
Sold in packs of 10.
