FSH FES10 Compact Electric Strikes

FSH FES10 Compact Electric Strikes From Allegion.

FSH FES10 Compact Electric Strikes – FSH FES10 Series Compact Electric Strikes from Allegion are designed specifically for residential and light commercial applications.

With a compact ANSI footprint, these electric strikes accept dual-voltage operation at either 12 or 24VDC and have a robust holding strength of up to 1000 kg, have CE/C-Tick certification and are backed by a 5-year warranty.

Featuring a stainless-steel faceplate and keeper, the FES10 series strikes can be configured on-site as either power to lock (PTL) or power to open (PTO) through a simple barbell mechanism adjustment. The devices support door latch depths of up to 15 mm and come pre-drilled for extension lips.

The FES10 series is tested for a fire rating of up to 4 hours in compliance with AS 1530.4:2005. The FES10M model includes door status sensor monitoring, while the standard FES10 model is weather resistant, rated to IP56, suitable for external applications.

You can contact Wesco Anixter Branches for more information here or read more SEN news here.

FSH FES10 Compact Electric Strikes Features:

• Compact ANSI footprint suitable for residential and light commercial use
• Dual voltage operation (12 or 24VDC)
• Field-changeable PTL/PTO functionality
• Up to 1000kg holding strength
• Up to 4-hour fire-rated compliance (AS 1530.4:2005)
• Stainless steel construction
• FES10M with Door Status Sensor monitoring
• FES10 model weather resistant (IP56)
• Pre-drilled for extension lips
• CE/C-Tick certified
• 5-year warranty.

“FSH FES10 Compact Electric Strikes From Allegion.”
