Magos SR250 Intrusion Detection Radar From Perimeter Systems Australia.
Magos SR250 Intrusion Detection Radar – Magos SR250 from Perimeter Systems Australia is a ground-based radar solution that offers site-wide intrusion detection.
Magos radars utilise MIMO and digital beam forming technology to deliver high resolution, coverage, and performance in cluttered environments, and in all weather and lighting conditions.
Magos’ radar range combines long range, high resolution (less than 1m), an angle resolution lower than 0.7 degrees, and wide coverage of up to 120 x 30 degrees, and the range offers a detection coverage between 6 acres and 200 acres, as well as a detection range from 150 metres to 1000 metres for a person, vehicle or boat, depending on which model you select. This SR250 can detect a person or a vehicle at a range of 250 metres.
Magos radar has very low power consumption of 3.5W at 48V DC, and the units are resistant in severe outdoor installations conditions, with an operating range of -40 to 85 degrees C, IP67 and NEMA 6 ratings against water and dust, and a UV-resistant housing.
Magos SR250 Intrusion Detection Radar
Other excellent features include low communications bandwidth of less than 100kbps, PoE interface, C-band frequency, MTBF of 50,000 hours with no moving parts, compact size of 250 x 150 x 59mm and light weight of 1.5kg.
Magos Area Surveillance Software (MASS+AI) is the real-time command and control system for monitoring the Magos radars input and controlling linked PTZ cameras, as well as managing the Magos AI solution.
It uses Magos radars for object detection and tracking, and AI algorithms for accurate video-based object classification, reducing nuisance alarms to near zero without compromising threat detection capabilities.
MASS integrates with all major site-security solutions, including VMS, access control, PSIM, etc, and is compatible with ONVIF-compliant PTZ cameras.
Magos SR250 Intrusion Detection Radar Features
- Multi-target classification of people, vehicles, and animals, while filtering out nuisance alarms
- Automatic control of any number of sensors and PTZ cameras
- Real-time handling of multiple threats
- Advanced class-based and geo-filtering delivers only relevant information
- Easily deployable web-based software with minimal system requirements
- AI-based automatic & accurate target classification, with no need for manual intervention
- BlueForce GPS based friendly target tracking.
